Description
Small mini monitor type loudspeakers have become very popular for those wishing for a high quality sound with a minimal visual effect.
The DB1 cabinet is slightly larger than the previous model; the cabinet is made from different thicknesses of high density MDF and further damped by bituminous damping to control cabinet resonance. A newly designed long throw bass driver with raised spider and linear motor system was used and ported at the rear. The cone is made from mikapulp which is then elastic coated and fitted with our ProAc acrylic pole damping phase plug. The new crossover was designed to give a flatter response at high levels and the tweeter is a ProAc 1 inch silk dome similar to that used in the ProAc Response D2.
Nominal Impedance: 8 ohms
Recommended Amplifiers: 20 to 100 watts
Frequency Response: 35Hz to 30kHz +/- 3dB 50Hz-20KHz
Sensitivity: 87.5 db linear for 1 watt at 1 metre
