Description
The Ultimate in Micro Engineering and Design
KEY FEATURES
Graded zero tolerance black anodised aluminium body
Boron rod cantilever
‘Fine line’ profile, nude diamond stylus
Iron micro cross and coil assembly making one of the worlds smallest MC generators
Worlds most powerful minaturised neodymium magnet
High specification fine wire 0.018 mm
TECHNICAL SPECIFICATIONS
Tracking Pressure: 1.9 g
Input Load Impedance: 100 Ω
Output Impedance : 10 Ω
Nominal Output Voltage: 350 μV
Channel Balance: ≥ 10 μV
Separation: ≥ -29 dB
Mass: 6 g
